Photo of the SHE button HE-080 with opened housing

EV-HE080 Firemans Override Switch

Name: EV-HE080 Firemans Override Switch
Brand: SIMON PROtec
SKU: EV-HE080
Price: 83.00 GBP
Availability: InStock

£83.00 / £99.60 incl. VAT

Electrical manual emergency override switch HE-080 orange

The HE 080 Orange is a main SHEV-button of electrical line-monitored SHEV systems (SHEV 3, SHEV 6, ESM-T / X, - tested according to DIN EN 12101-9), whose board is interchangeable. The "UP" and "CLOSE" buttons are included.
On the main SHEV-button there are three LED indicators for SHEV (according to the VdS guideline 2592 and in the sense of the MBO): "triggered" = red, "ready" = green and "fault" = yellow. A buzzer signals a trip or a fault. This can be eliminated with the mute key (inclusive).

The HE 080 is available in impact-resistant plastic housing (ABS), in accordance with DIN 14655, in RAL color 2011 and complete with thin-glass disc and key as a unit.

Dimensions: 125 * 125 * 36 mm (H * W * D)

Available for Next Working Day Dispatch

SKU: EV-HE080 Category: Switches and Sensors Tags: Sensors, SIMON PROtec, Smoke Ventilation, Switches Brand: SIMON PROtec

The electrical SHEV emergency button type HE 080 Orange is used as a main or secondary SHEV-button (in accordance with DIN 18232/2 and LBO) in smoke and heat extraction systems. In case of fire, the respective electrical control unit is controlled manually by the heat and smoke extraction button and activates the smoke extraction.

Acoustic signal in the event of an alarm or fault

The main SHEV-button is equipped with a buzzer, which emits an acoustic signal in the event of an alarm or fault. The signal can be reset using the mute button.

Manual control device at a glance:

Can be used as main and secondary SHEV-button
Reliable activation of the electrical control device in case of fire
available with integrated buzzer
Resettable with mute button

Under the Construction Products Regulations (CPR) it is a legal requirement to use only certified products for smoke ventilation. It is the responsibility of the installer to ensure installations meet the relevant standards. For more information see SCS Group’s Technical Bulletin.

Article name	Main SHEV button type HE 080 Orange
Input voltage	24 V DC
IP code	IP40
Weight	0.2 kg
Housing width	125 mm
Housing height	125 mm
Nominal working temperature	20 °C
Environment temperature range	-5 °C - 75 °C
Housing	Surface-mounted plastic housing, optionally in flush-mounted housing with rotating door, impact glass and key
Appliance class	III
Housing type
LED signs	Red = Triggering (SHEV ON)Yellow = breakdownGreen = ready
Housing depth	36 mm
